Stripe Billing Analytics to BigQuery

stripe-bigquery is a focused Stripe billing analytics pipeline for BigQuery. It loads the customer, product, price, subscription, subscription-item, and invoice resources into stripe_raw; builds reusable billing models in stripe_stage; and publishes recurring-revenue and invoice-billing reports in stripe_reports.

The template contains 19 assets across three layers. It is a practical starting point for analyzing Stripe subscription billing while keeping the data model small enough to adapt to your own reporting needs.

Project structure

stripe-bigquery/
├── pipeline.yml
├── README.md
├── dashboards/
│   └── stripe-billing-analytics.yml
└── assets/
    ├── stripe_raw/
    │   ├── customer.asset.yml
    │   ├── product.asset.yml
    │   ├── price.asset.yml
    │   ├── subscription.asset.yml
    │   ├── subscription_item.asset.yml
    │   └── invoice.asset.yml
    ├── stripe_stage/
    │   ├── customers.sql
    │   ├── products.sql
    │   ├── prices.sql
    │   ├── subscriptions.sql
    │   ├── subscription_items.sql
    │   ├── invoices.sql
    │   ├── invoice_line_items.sql
    │   ├── subscription_item_daily_snapshot.sql
    │   └── customer_currency_daily_mrr_snapshot.sql
    └── stripe_reports/
        ├── monthly_mrr_by_customer.sql
        ├── monthly_mrr_movements.sql
        ├── monthly_subscription_kpis.sql
        └── monthly_invoice_billings.sql

What it creates

Raw Stripe data

The stripe_raw dataset contains the six Stripe resources that underpin the billing models. Ingestr loads them with the shared stripe-default connection, and BigQuery is the destination.

Each source asset uses ingestr's incremental Stripe mode (<endpoint>:sync:incremental) with a merge materialization keyed on the Stripe object id, so a run only fetches the records created inside its own time window and upserts them.

Incremental mode filters on Stripe's created timestamp and does not revisit records created in earlier windows. That matters for the mutable resources — a subscription cancelled or upgraded months after it was created, an invoice finalized, paid, or voided after its creation date. To pick those edits up, periodically re-run over a wider window:

bruin run --start-date 2023-01-01 --end-date $(date -u +%F) my-stripe-pipeline

Choose that cadence to match how current your reporting needs to be, or switch the mutable assets to source_table: subscription for standard async loading, which reloads full history on every run. See loading modes and trade-offs for the comparison.

Each raw asset also declares its full column schema, which pins those columns into the destination table. That matters for fields Stripe leaves null on some accounts: invoice.due_date is only set for invoices collected with send_invoice, and a schema inferred purely from the data would drop the column and break the stage model.

Conformed billing models

The stripe_stage dataset exposes typed customer, product, price, subscription, subscription-item, invoice, and invoice-line-item models. It also builds daily snapshots of subscription items and customer MRR by native currency, stamped with the pipeline end date.

Every stage and report asset is materialized as a CREATE OR REPLACE TABLE, so each run rebuilds its table from the current raw data. That keeps the pipeline idempotent and easy to reason about, and it also means the snapshot tables hold only the most recent run's observation rather than an accumulated history. To retain a snapshot history, switch the two snapshot assets to an incremental strategy such as merge on their existing primary keys.

Billing reports

The stripe_reports dataset provides four ready-to-query tables:

• monthly_mrr_by_customer — month-end observed MRR and annualized run rate by billing customer and currency.
• monthly_mrr_movements — customer-level new, reactivation, expansion, contraction, and churn movements.
• monthly_subscription_kpis — recurring-revenue, retention, and customer-count metrics by currency.
• monthly_invoice_billings — non-draft, non-void invoice billings by finalization month, with a labeled creation-date fallback.

Column-level documentation

Every asset in all three layers declares its full column schema: each column carries a type, a description, and primary-key marks on the grain, so the reporting grain and the metric definitions are readable from the asset files themselves. metadata_push in pipeline.yml publishes those descriptions to the BigQuery table and column metadata, and bruin docs my-stripe-pipeline generates a browsable documentation site from the same schemas.

Example report rows

The following illustrative rows use minor currency units: 9900 USD means $99.00. They show the shape of each table across several months, which assumes retained snapshot history; see Conformed billing models. Query the four tables in stripe_reports directly, then adapt the columns to the definitions used by your finance and revenue teams.

monthly_mrr_by_customer

metric_month	as_of_snapshot_date	stripe_customer_id	currency	active_subscription_count	ending_mrr_minor	run_rate_arr_minor
2026-01-01	2026-01-31	cus_acme	usd	1	9900	118800
2026-02-01	2026-02-28	cus_acme	usd	1	12900	154800
2026-02-01	2026-02-28	cus_pine	usd	2	4900	58800

monthly_mrr_movements

metric_month	stripe_customer_id	currency	beginning_mrr_minor	ending_mrr_minor	expansion_mrr_minor	churned_mrr_minor	movement_type
2026-02-01	cus_acme	usd	9900	12900	3000	0	expansion
2026-02-01	cus_oak	usd	2500	0	0	2500	churn
2026-02-01	cus_pine	usd	0	4900	0	0	new

monthly_subscription_kpis

metric_month	currency	ending_mrr_minor	new_mrr_minor	expansion_mrr_minor	churned_mrr_minor	ending_active_customer_count	net_revenue_retention_rate_excluding_reactivation
2026-01-01	usd	12400	12400	0	0	2	—
2026-02-01	usd	17800	4900	3000	2500	2	1.04
2026-02-01	eur	8100	0	1100	0	1	1.16

monthly_invoice_billings

invoice_billing_month	invoice_billing_date_basis	currency	issued_invoice_count	subscription_invoice_count	invoiced_billings_minor	invoiced_subscription_billings_minor
2026-01-01	invoice_finalized_at	usd	14	12	139400	128700
2026-02-01	invoice_finalized_at	usd	16	13	171800	160200
2026-02-01	invoice_created_at_fallback	eur	2	2	16200	16200

Metric policy

All monetary values remain in each currency's minor units. Do not add amounts across currencies without an FX source and explicit conversion policy.

MRR is a gross list-price run rate from active and past-due subscriptions with licensed recurring monthly or annual prices. Free, one-time, metered, and discounted amounts are excluded. Run-rate ARR is MRR multiplied by 12; neither measure is recognized revenue, bookings, cash, or a financial statement.

The daily snapshots capture the Stripe state visible when the pipeline runs. They do not reconstruct prior daily MRR history from current Stripe records, and because every asset is rebuilt with create+replace, each run keeps only the latest observation. Month-over-month movement and retention metrics therefore need snapshot history retained first.

Configure connections

Initializing the template adds placeholder connections to the repository-level .bruin.yml. Keep the connection names gcp-default and stripe-default, or rename them consistently in both .bruin.yml and pipeline.yml.

default_environment: default

environments:
  default:
    connections:
      google_cloud_platform:
        - name: gcp-default
          project_id: your-gcp-project-id
          location: your-gcp-region
          use_application_default_credentials: true
      stripe:
        - name: stripe-default
          api_key: ${STRIPE_API_KEY}

Replace both BigQuery placeholders before running the pipeline:

• project_id — the Google Cloud project that owns the BigQuery datasets this pipeline writes to, for example my-company-analytics.
• location — the region or multi-region of those datasets, for example US, EU, or europe-west3. It must match the location of the existing datasets; BigQuery cannot query a dataset from a different location. See BigQuery locations.

The connection uses Application Default Credentials, so authenticate with gcloud once:

gcloud auth application-default login

To use a service account instead, replace use_application_default_credentials: true with service_account_file: /path/to/service-account.json. Either way, the credentials need permission to create datasets and tables and to run queries in the project.

Set the Stripe secret key in your shell before running the pipeline:

export STRIPE_API_KEY='sk_test_your_secret_key'

Use either an sk_test_... or sk_live_... secret key. A publishable pk_... key cannot read Stripe data. Keep test and live data in separate BigQuery projects or datasets and do not commit credentials. The ingestr docs cover where to find the key and how to create a restricted key with read-only access to the resources this pipeline loads.

Run the pipeline

Initialize a project from the template:

bruin init stripe-bigquery my-stripe-pipeline

Set start_date in pipeline.yml to the earliest Stripe history you need, then run the fast validation checks:

bruin validate --fast my-stripe-pipeline

On a new BigQuery destination, load every table before running query validation. The raw assets load only their run window, so pass an explicit range to pull your Stripe history in the first load:

bruin run --start-date 2023-01-01 --end-date $(date -u +%F) \
  --no-validation my-stripe-pipeline

After the initial load, run bruin validate my-stripe-pipeline and schedule the pipeline daily. The stage and report assets are rebuilt with create+replace, so any run is safe to repeat; the raw assets upsert on id, so re-running a window does not duplicate rows.

Customize it

Use the stage models as a stable interface for your own reports. Review the selected assets, source fields, quality checks, and metric policy before using the results for financial reporting. Extend the pipeline with your business definitions, identity mapping, and FX policy where required.

View the billing dashboard

The included DAC dashboard visualizes native-currency MRR, ARR, customer count, retention, movement components, invoice billings, and the latest customer MRR distribution. It deliberately filters to one currency at a time because the reporting tables retain money in native minor units and do not apply FX rates.

After configuring gcp-default, install a verified DAC release by following the DAC installation guide. Then install its dashboard-authoring skill from the project root:

dac skills install --dir . create-dashboard

Restart your coding agent after installing the skill so it can use the local create-dashboard instructions. Then validate the dashboard, execute its queries, and serve the DAC app:

dac --config .bruin.yml validate --dir dashboards
dac --config .bruin.yml check --dir dashboards
dac --config .bruin.yml serve --dir dashboards --port 8321

Dashboard preview

This screenshot uses synthetic data solely to demonstrate the dashboard's layout and charts.

MRR movement and retention metrics need two contiguous monthly snapshots, so they stay empty while the snapshot tables are rebuilt with create+replace on every run.
